Input connectors
− 2x 3G-SDI
− 1x HDMI 2.0
− 4x SL-DVI
16 Ethernet output ports load up to 10,400,000 pixels
3x independent layers and 1x OSD
− 1x 4K×2K main layer
2x 2K×1K PIPs (PIP 1 and PIP 2)
− Adjustable layer priorities
− 1x OSD
DVI mosaic
Up to 4 DVI inputs can form an independent input source, which is DVI Mosaic
Decimal frame rate supported
Supported frame rates include 23.98 Hz, 29.97 Hz, 47.95 Hz, 59.94 Hz, 71.93 Hz and 119.88 Hz.
3D
Supports 3D display effect on the LED screen. The device output capacity will be halved after the 3D function is
enabled.
Personalized image scaling
Three scaling options are pixel-to-pixel, full screen and custom scaling.
Image mosaic
Up to 4 devices can be linked to load a super large screen when used together with the video distributor.
Intuitive device operation and control via V-Can
Up to 10 presets can be saved for future use
EDID management
Custom EDID and standard EDID supported
Device backup design
In backup mode, when the signal is lost or the Ethernet port fails on the primary device, the backup device will take over the task seamlessly.
Supports input source hot backup
Ethernet port backup test
Test whether the pre-stored images, backup Ethernet ports and devices take effect without plugging and unplugging the Ethernet cables
