Input connectors
1x HDMI 1.3 (IN & LOOP)
− 1x HDMI 1.3
− 1x 3G-SDI (IN & LOOP)
Output connector
− 4x Gigabit Ethernet ports
A single device unit drives up to 2.6 million
pixels, with a maximum width of 3840 pixels
and a maximum height of 3840 pixels.
Audio input and output
− Audio input accompanied with an HDMI
input source
− Audio output via a multifunction card
− Output volume adjustment supported
Output synchronization
An internal input source can be used as the
sync source to ensure the output images of all
cascaded units in sync.
2x layers
− Adjustable layer size and position
− Adjustable layer priority
Powerful video processing
− Based on SuperView III image quality
processing technologies to provide stepless
output scaling
− One-click full screen display
− Free input cropping
Easy preset saving and loading
Up to 10 user-defined presets
Multiple kinds of hot backup
− Backup between devices
− Backup between Ethernet ports
− Input source hot backup
Ethernet port backup test
Test whether the pre-stored images, backup
Ethernet ports and devices take effect without
plugging and unplugging the Ethernet cables.
Up to 4 units cascaded for image mosaic
Output image quality management
Brightness, saturation, contrast and hue
adjustment
Pixel level brightness and chroma calibration
Working with LCT and calibration software to
support brightness and chroma calibration on
each LED, effectively removing color
discrepancies and greatly improving LED
display brightness and chroma consistency,
allowing for better image quality.
Multiple operation modes
Control your device as you wish via LCT or
device front panel knob and buttons.
